| Power: | |
|---|---|
| Driven type : | |
| Weight: | |
| Quantity: | |
CCM2
CCME
Key feature:
Optimized combination of diameter-rotate speed of propeller, that improve propulsion efficiency; In the same thrust force we have smaller diameter, improve the ratio of utilization of cabin;
Skew blade and large disk ratio, reduce vibration and improve cavitation performance;
Gear and bearing have high strength and long longevity, and dipped into oil to got better lubrication and cooling effect, which improving the reliability of TP;
Underwater structure are optimized so that it have rational construction, which convenient for maintenance and repairing.
Tail shaft sealing are enough reliable sealing, meet the strict requirements of anti-pollution law of sea and ocean environment
| Type | Propeller Dia. Max.(mm) | Input Power Max.(kw) | Input Speed (RPM) | Frequency (Hz) | Max. Thruster (kN) | Reduction Ratio | Standard Inner (mm) | Propeller Type |
| TT500 | 500 | 63 | 1450 | 50 | 10 | 1.52 | 515 | FP |
| 72 | 1750 | 60 | 11.2 | |||||
| TT600B | 600 | 63 | 1450 | 50 | 10 | 1.52 | 615 | FP |
| 72 | 1750 | 60 | 11 | |||||
| TT600 | 600 | 90 | 1450 | 50 | 14.5 | 2.071 | 615 | FP |
| 105 | 1750 | 60 | 16.3 | |||||
| TT700 | 700 | 140 | 1450 | 50 | 21 | 2.071 | 715 | FP |
| 165 | 1750 | 60 | 24.8 | |||||
| TT800B | 800 | 140 | 1450 | 50 | 21 | 2.071 | 818 | FP |
| 165 | 1750 | 60 | 26 | |||||
| TT800 | 800 | 180 | 1450 | 50 | 29.5 | 2.417 | 818 | FP |
| 190 | 1750 | 60 | 30.5 | |||||
| TT900 | 900 | 250 | 1450 | 50 | 40 | 2.417 | 918 | FP |
| 300 | 1750 | 60 | 46 | |||||
| TT1100B | 1100 | 250 | 1450 | 50 | 40 | 2.417 | 1132 | FP |
| 300 | 1750 | 60 | 46 | |||||
| TT1000 | 1000 | 280 | 1450 | 50 | 43 | 3.09 | 1032 | FP/CP |
| 290 | 1750 | 60 | 15.2 | |||||
| TT1100 | 1100 | 315 | 1450 | 50 | 49 | 3.09 | 1132 | FP/CP |
| 340/335 | 1750 | 60 | 53.8 | |||||
| TT1300B | 1300 | 400 | 1450 | 50 | 62 | 3.7 | 1340 | FP/CP |
| 440 | 1750 | 60 | 64 | |||||
| TT1300 | 1300 | 445 | 1450 | 50 | 67 | 3.78 | 1340 | FP/CP |
| 480 | 1750 | 60 | 73 | |||||
| TT1480 | 1480 | 560 | 1450 | 50 | 88 | 4.364 | 1520 | FP |
| 620 | 1750 | 60 | 95 | |||||
| TT1650 | 1650 | 680 | 1450 | 50 | 105 | 4.727 | 1692 | FP/CP |
| 730 | 1750 | 60 | 110 | |||||
| TT1800 | 1800 | 900 | 1450 | 50 | 135 | 4.455 | 1842 | FP/CP |
| 750 | 1190 | 60 | 116 | |||||
| TT2000 | 2000 | 1050 | 1450 | 50 | 165 | 4.82 | 2038 | FP/CP |
| 900 | 1190 | 60 | 150 | |||||
| TT2200 | 2200 | 1150 | 980 | 50 | 186 | 4.65 | 2242 | FP/CP |
| 1400 | 1190 | 60 | 220 | |||||
| TT2400 | 2400 | 1580 | 980 | 50 | 250 | 4.636 | 2442 | FP/CP |
| 1720 | 1190 | 60 | 260 | |||||
| TT2800 | 2800 | 2000 | 980 | 50 | 298 | 4.395 | 2848 | CP |
