| Working pressure : | |
|---|---|
| Temperature range: | |
| Quantity: | |
CCM2
CCME
construction
Characteristics:Flexible,Anti-wave,Wear-resistance,Weather-resistance,Aging resistance, seawater
resistance
Working pressure: 10 to 25bar
Temperature range: -30 to +80 ℃
Safety factor: 1:3
Technical parameters:
Hose lining: NR, SBR,BR
Reinforcement layer: tire cord
Floating layer: PE foam
Cover rubber layer: SBR and CR blend
| ID | OD | Length | Bending angle |
| mm | mm | mm | ° |
| 650 | 1260 | 11800 | 0°- 45° |
| 700 | 1440 | 11800 | 0°- 45° |
| 750 | 1460 | 11800 | 0°- 45° |
| 850 | 1640 | 11800 | 0°- 45° |
| 1000 | 1800 | 11800 | 0°- 45° |
| Remark:We can produce other specification according to customers' requirements | |||
construction
Characteristics:Flexible,Anti-wave,Wear-resistance,Weather-resistance,Aging resistance, seawater
resistance
Working pressure: 10 to 25bar
Temperature range: -30 to +80 ℃
Safety factor: 1:3
Technical parameters:
Hose lining: NR, SBR,BR
Reinforcement layer: tire cord
Floating layer: PE foam
Cover rubber layer: SBR and CR blend
| ID | OD | Length | Bending angle |
| mm | mm | mm | ° |
| 650 | 1260 | 11800 | 0°- 45° |
| 700 | 1440 | 11800 | 0°- 45° |
| 750 | 1460 | 11800 | 0°- 45° |
| 850 | 1640 | 11800 | 0°- 45° |
| 1000 | 1800 | 11800 | 0°- 45° |
| Remark:We can produce other specification according to customers' requirements | |||
