CCM-3
CCME
Benefits of Plastic Rotomolding
•Custom roto-molded costs are significantly less than other custom plastic molding processes.
•The rotational molding process allows for quick turnaround from concept to production.
•Roto Molding does not force plastic into a shape. Forced air molding makes uneven, low-quality products. Rotomolded plastic products are even and durable.
Custom Rotational Molding for Plastic Product Designs
Item No. | specification | Buoyancy (100% drown) | Quantity | |||
Length | Width | Height | For 20’GP | For 40’GP | ||
PF-004 | 1200mm | 800mm | 550mm | 520kg | 56pcs | 120pcs |
PF-004H | 1200mm | 800mm | 650mm | 620kg | 40pcs | 85pcs |
PF-005 | 1800mm | 1400mm | 400mm | 1000kg | 26pcs | 54pcs |
PF-007 | 1420mm | 900mm | 550mm | 700kg | 43pcs | 89pcs |
PF-007H | 1420mm | 900mm | 650mm | 830kg | 34pcs | 70pcs |
PF-007T | 1420mm | 900mm | 700mm | 890kg | 32pcs | 68pcs |
PF-008 | 1200mm | 610mm | 500mm | 360kg | 76pcs | 165pcs |
PF-009 | 1200mm | 1100mm | 500mm | 660kg | 44pcs | 96pcs |
PF-009H | 1200mm | 1100mm | 620mm | 810kg | 36pcs | 76pcs |
PF-010 | 1730mm | 1185mm | 600mm | 1230kg | 17pcs | 40pcs |
PF-011 | 1380mm | 950mm | 550mm | 720kg | 40pcs | 83pcs |
PF-011H | 1380mm | 950mm | 650mm | 850kg | 33pcs | 66pcs |
PF-012 | 1650mm | 620mm | 500mm | 510kg | 55pcs | 117pcs |
PF-012WR | 1650mm | 920mm | 500mm | 750kg | 34pcs | 75pcs |
PF-012WT | 1650mm | 960mm | 500mm | 790kg | 30pcs | 62pcs |
PF-013 | 1580mm | 1180mm | 650mm | 1210kg | 21pcs | 44pcs |
PF-016 | 1200mm | 660mm | 550mm | 435kg | 69pcs | 144pcs |
Roto molding is the best solution for plastic prototype molding. Not only is the rotomolding process cost-effective, rotationally molded plastic comes in all shapes and sizes. Any concept is valid, large or small, and can be produced in large or small quantities.
we are specialized in planning designing, producing and installing of yacht marina, pontoons bridges, floating docks, floating platform floating houses as well as relative equipment.
