| Thickness : | |
|---|---|
| Length: | |
| Quantity: | |
CCM4
CCME
High-density polyethylene pipe(HDPE pipe) is made from high density polyethylene as the main raw material, adding a small amount of antioxidants, Anti-UV absorbers and pigments.
O.D(mm) | Standard Dimensions | ||||
SDR33 | SDR21 | SDR17 | SDR13.6 | SDR11 | |
Normal Pressure(Mpa) | |||||
0.4 | 0.6 | 0.8 | 1 | 1.25 | |
e(mm) | e(mm) | e(mm) | e(mm) | e(mm) | |
25 | 2.3 | ||||
40 | 3.7 | ||||
50 | 4.6 | ||||
63 | 4.7 | 5.8 | |||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 10 | |
110 | 5.3 | 6.6 | 8.1 | 10 | |
160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 |
200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 |
250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 |
315 | 9.7 | 15 | 18.7 | 23.2 | 28.6 |
355 | 10.9 | 16.9 | 21.1 | 26.1 | 32.3 |
450 | 13.8 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 15.3 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 17.2 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 19.3 | 30 | 37.4 | 46.3 | 57.2 |
High-density polyethylene pipe(HDPE pipe) is made from high density polyethylene as the main raw material, adding a small amount of antioxidants, Anti-UV absorbers and pigments.
O.D(mm) | Standard Dimensions | ||||
SDR33 | SDR21 | SDR17 | SDR13.6 | SDR11 | |
Normal Pressure(Mpa) | |||||
0.4 | 0.6 | 0.8 | 1 | 1.25 | |
e(mm) | e(mm) | e(mm) | e(mm) | e(mm) | |
25 | 2.3 | ||||
40 | 3.7 | ||||
50 | 4.6 | ||||
63 | 4.7 | 5.8 | |||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 10 | |
110 | 5.3 | 6.6 | 8.1 | 10 | |
160 | 4.9 | 7.7 | 9.5 | 11.8 | 14.6 |
200 | 6.2 | 9.6 | 11.9 | 14.7 | 18.2 |
250 | 7.7 | 11.9 | 14.8 | 18.4 | 22.7 |
315 | 9.7 | 15 | 18.7 | 23.2 | 28.6 |
355 | 10.9 | 16.9 | 21.1 | 26.1 | 32.3 |
450 | 13.8 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 15.3 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 17.2 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 19.3 | 30 | 37.4 | 46.3 | 57.2 |
