| Weight: | |
|---|---|
| Floating buoy: | |
| Size: | |
| Quantity: | |
CCM3
CCME
Floating pontoon cubes
1.Unlimited Number of Construction
The pontoons of the construction can adapt to any specific lakeside residen's needs and can be assembled to correnspond with the shape or size you have in mind. The possible number of construction is unlimited.
2.Fast and Easy to Assemble
Only 2 people are needed to put together 50 cubes in a one hour period.The pontoon construction is very simple, blocks held together tightly and filmly with special connecting pins. All parts are light weight and easy to handle.
3.Light Weight, Robust and Safe
The safety aspect of nautical products is very important. This is why we had rigorous tests. Amongst its satety characteristics there are: great stablility of our dock, its loading capacity and also its non-slip surface.
4.Economy
Ocean pontoon is low maintenance and upkeep. You will waste no more time, money or long work hours to redo it year after year like with conventional wood or metal constrction.
Configuration Parts
Connection Pin
Size:Dia. 185*48*245mm
It is used to lock the pontoon lugs together. When the pin is pushed in and turned, a quarter turn locks the cube lugs together using two different locking systems. This ensures a superior locking.
Side Fixation with Nut
Size: Dia. 95*205mm
The bolt and nut are used around the outside edge of the modular system assembly. Where tow float edges meet, the two lugs are locked together by the nut and bolt side fixation.
Distance Disc
Size:Dia. 96*32mm, Dia. 96*16mm
Pontoons are equipped with 4 lugs, position at various heights. Due to the sapce created between them, the spacer will be used to fill this empty space. Sapcers are mainly used for the side fixation assemble.
Boat Cleat
Size: Dia. 76*250mm
Cleat used to anchor your boat to the dock
Modualr Floating pontoons size
No. | Dimension | Unit weight | Floating buoyancy Kg (100% Drown) | Thickness | Quantity for 40HQ container pc |
1 | 1200x800x550 | 30.5 | 490 | 5mm | 123 |
2 | 1200x800x650 | 35.8 | 580 | 5mm | 90 |
3 | 1200x800x800 | 42 | 720 | 5mm | 75 |
4 | 1420x900x550 | 40 | 660 | 5mm | 97 |
5 | 1650x920x650 | 47.5 | 830 | 5mm | 68 |
6 | 1650x960x650 | 48.5 | 870 | 5mm | 66 |
7 | 1700x1180x650 | 60 | 1140 | 5mm | 54 |
8 | 1200x800x1050 | 55 | 950 | 5mm | 60 |
1. It allows an inaccuracy of 5± % technical figure.
2. To open a new mold for customized size, extra cost is USD3000 per one mold. Mold-opening time is around 15 days
3. Color: usually it is black or blue color.
4. The E.P.S content in the pontoon has a 0.94lbs per cubic foot density.
