Marine Cleat Fairlead with Single Roller

CB 436-2000 cleat fairlead with single roller has two types:type A and type B. CB 436-2000 type A adopted the Standard CB 58-83 Roller Fairlead and Standard GB/T1010-88 Marine Roller.CB 436-2000 is strictly produced in line with the quality standard.Besides,this kind of fairlead is issued by IACS.So please feel free to contact us if you are interested in any of our products.

Material:
Feature :
Certificate :
Quantity:
  • CCM3
  • CCME

We can produce all kinds of deck mooring fittings: Chock, roller fairlead,bollard,mooring bitt,bleat and chain stopper etc:

1, Chock: Chock DIN 81915, Closed chock JIS F2005-1975,Mooring chock JIS F2007-1976,Panama chock JIS F2017-1982 type AC and BC, Cast roller chock

2, Roller fairlead:Warping roller DIN 81906,Warping roller with socket DIN 81907, conical warping roller with socket DIN 81907 form A, cylindrical Fairlead roller JIS F2014-1987, Horizontal fairlead with roller, Steel plate deck end roller JIS F2004 type A, B and C,EU type roller

3, Bollard: Bollards type NS2584,JIS F2001-1990 and GB554-83 standard, welding bollards GB556-65,
4, Chain stopper: Chain cable stopper JIS F2023-1976 Cast steel bar type chain cable stopper JIS F2015-1987, Cast steel pawl type chain stopper for anchor chain

5, Ship's manhole, mooring bitt, cleat, strong point, smit bracket etc.



Rated towing pull

Rope

(mm)

Wre size (mm)

A

(mm)

B

C

D

E

F

G

weight

20KN

-12

12

180

100

650

80

446

170

10

75kg

30KN

-16

16

230

130

800

100

546

210

10

130kg

50KN

-20

20

250

130

900

120

626

250

15

220kg

80KN

-24

24

280

160

1000

140

716

288

20

320kg

120KN

-32

32

300

160

1200

180

836

366

25

580kg

200KN

-40

40

320

180

1350

245

1030

500

35

1100kg

320KN

-48

40

400

250

1700

300

1236

610

45

2210kg
