Oil Spill Containment Boom is economic and general propose boom for encircling spilt oil and other floaters on water. It is especially suitable for permanent deployment and widely used at pond, lake, river, harbor and offshore petroleum platform.
The rubber boom is made of double strength synthetic fiber cloth which is covered with good quality synthetic rubber.
It is oil-resisting, wear-resisting, seawater-resisting, and ultraviolet ray ageing-resisting.
The unique configuration of floats has great buoyancy reserve, and high intensity and stability.
Universal connectors make quick and reliable connection impossible.
Technical data
Model/Parameter | DT600 | DT700 | DT750 | DT800 | DT900 | DT1000 | DT1100 |
Overall height(mm) | 600 | 700 | 750 | 800 | 900 | 1000 | 1100 |
Freeboard(mm) | 150 | 210 | 260 | 280 | 320 | 340 | 370 |
Draft(mm) | 380 | 390 | 400 | 420 | 490 | 540 | 560 |
Max, working tensile strength(mm) | 20 | 25 | 30 | 45 | 55 | 75 | 85 |
Length per section (m) | 20 | ||||||
Max, wave height to withstand(m) | 0.5 | 0.5 | 1 | 1.5 | 1.8 | 2 | 2 |
Max, wind speed to withstand(m/s) | 8 | 10 | 10 | 15 | 15 | 18 | 20 |
Max, current speed to with stand(KN) | 1 | 1 | 1.5 | 1.5 | 2 | 2.5 | 2.5 |
Standard connector | ASTM or Stainless steel | ASTM or Stainless steel | ASTM or Stainless steel | ASTM or Stainless steel | ASTM or Stainless steel | ASTM or Stainless steel | ASTM or Stainless steel |
packing dimensions for 20m(m) | 1x1x0.6 | 1.2x1x1 | 1.2x1x1 | 1.3x1.1x1.1 | 1.4x1.5x1.2 | 1.4x1.6x1.3 | 1.4x1.7x1.4 |
