| Diameter : | |
|---|---|
| Load capacity : | |
| Tensile Strength: | |
| Quantity: | |
CCM3
CCME
Material: Stainless steel
Grade: 304, 316
Construction: 7x19
Standard: AISI, ASTM, GB, JIS, DIN, EN
Diameter: 0.1-40mm
Tensile strength: 1570N/mm2
Certificate: ISO, SGS
Packaging: 3000m/reel
| Standard: | ||||||||
| Grade | C % | Ni % | Cr % | P % | S % | SI % | Mn % | Mo % |
| 304 | ≤0.08 | 8-10 | 18-20 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| 316 | ≤0.08 | 10-14 | 16-18 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
| 304L | ≤0.03 | 8-10 | 18-20 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| 316L | ≤0.03 | 10-14 | 16-18 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
| AISI304 | ≤0.07 | 8-10 | 17-19 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| AISI316 | ≤ 0.08 | 10-14 | 16-18 | ≤0.045 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
Our Main products:
1.Stainless Steel Wire Rope
2.Galvanized&Ungalvanized Steel Wire Rope
3.Compacted Strand Rope and Wire Rope
4.PVC/Nylon/PE coated Wire Rope
Construction: 1x7 , 1x12 , 1x19 ,1x37, 6x7, 6x19, 6x36 , 6x37 , 7x7 , 7x19 ,7x37 , etc.,
Diameter from 0.1 to 160 mm.
5. Stainless Steel Link Chain
6. Wire Rope Fittings
Material: Stainless steel
Grade: 304, 316
Construction: 7x19
Standard: AISI, ASTM, GB, JIS, DIN, EN
Diameter: 0.1-40mm
Tensile strength: 1570N/mm2
Certificate: ISO, SGS
Packaging: 3000m/reel
| Standard: | ||||||||
| Grade | C % | Ni % | Cr % | P % | S % | SI % | Mn % | Mo % |
| 304 | ≤0.08 | 8-10 | 18-20 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| 316 | ≤0.08 | 10-14 | 16-18 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
| 304L | ≤0.03 | 8-10 | 18-20 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| 316L | ≤0.03 | 10-14 | 16-18 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
| AISI304 | ≤0.07 | 8-10 | 17-19 | ≤0.035 | ≤0.03 | ≤1.0 | ≤2 | |
| AISI316 | ≤ 0.08 | 10-14 | 16-18 | ≤0.045 | ≤0.03 | ≤1.0 | ≤2 | 2-3 |
Our Main products:
1.Stainless Steel Wire Rope
2.Galvanized&Ungalvanized Steel Wire Rope
3.Compacted Strand Rope and Wire Rope
4.PVC/Nylon/PE coated Wire Rope
Construction: 1x7 , 1x12 , 1x19 ,1x37, 6x7, 6x19, 6x36 , 6x37 , 7x7 , 7x19 ,7x37 , etc.,
Diameter from 0.1 to 160 mm.
5. Stainless Steel Link Chain
6. Wire Rope Fittings
